PLC Splitter Module Single Mode

Description

The indoor plc splitter module is one of the important passive components in the fiber link. A fiber-optic tandem device with multiple inputs and multiple outputs. Especially suitable for connecting central office and terminal in passive optical network (EPON, GPON, BPON, etc.). The device also implements the splitting of the optical signal.Box splitter is designed to be installed in a 19-inch standard rack and splitter unit. The types are O-type, L-type, P-type, S-type, R-type, and U-type, which are in full compliance with industry standards.

PLC Splitter

Features

  • Low Insertion loss;
  • Low PDL;
  • Compact Design;
  • Good channel-to-channel uniformity;
  • Wide Operating Wavelength: 1260-1650nm;
  • High Reliability and Stability.

The main technical parameter

Product Name plc splitter module inserting
configuration 1×8
Wavelength(nm) 1260-1650
Insertion Loss(dB) ≤10.7
PDL(dB) ≤0.3
Uniformity(dB) ≤0.8
Return Loss(dB) ≥50
Directivity(dB) ≥55
Temperature Range(℃) (-40~+75)
Storage Temprature(℃) (-40~+85)
