11ac 1200Mbps Dual Band inWall Access Point
11ac IN wall mount style wireless access point upgrade to the latest wireless-AC technology, fast data rate (900Mbps in 5G and 300Mbps in 2.4GHz) and dual band allowing content to download faster, large video or music files to sync more quickly and stream seamlessly. Embed PoE, work in hotel, school, hospital mainly for a stable wireless networking. Then work with Access Controller System and cloud management system, easy in central configuration, meet with different advertisement and multi authentication requirement , professional and cost effectively in large area wifi solution
It support 802.3af PoE, compliant with any 802.3af Power over Ethernet equipment, easy in setting and complete the full wifi coverage.
Support AC Controller and cloud Controller easy management or advertisement or portal authentication: the IT staff can sets up different IP addresses, ESSID and manages each room’s AP at the same time. They can remotely add, set up, monitor, delete, upgrade firmware via the AC controller through computer
| Wireless Standards | IEEE 802.11ac/n/a 5GHz; IEEE 802.11n/g/b 2.4GHz
|
| Management | Cloud controller & Hardware AC Controller |
| Frequency | 5GHz and 2.4GHz
|
| Signal Rate | 5GHz:Up to 900Mbps; 2.4GHz: Up to 300Mbps
|
| EIRP | <20dBm(EIRP)
|
| Wireless | Auto-Channel selection |
| Distance Control (802.1x Ack timeout) | |
| Multiple SSID | |
| BSSID | |
| Operation Mode | Wireless AP, Gateway, WiFi Repeater |
| Wireless Security | 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption |
| LED Status | Sys(System), WAN, WiFi
|
| Management | |
| System Settings | Web-based configuration (HTTP/Telnet), Access Control System (SNMP)
|
| Firmware Upgrade | Upgrade firmware via web browser or TFTP |
| Administration | Admin Password can be configured |
| System monitoring | Watch dog, Status in hand , useful statistic and Event log |
| Logs | Supports local logs, logs host, logs file export |
| Reset | Reset or factory defaults |
| Backup | Restore settings & configuration of the device to local file, Scheduled reboot
|
